Haro Subvert HT5
This item is currently not available.
Details
Wider is better. The Subvert HT5 uses 27.5 x 2.8-inch tires to create a trail-ready hardtail that crushes gnarly rock gardens and root-infested singletrack. The HT5's 6061-T6 high-end aluminum alloy frame with internal cable routing is paired with a 120mm suspension fork and Boost alloy disc hubs to match and complement oversize rubber. This mid-level build includes a dependable 1x11 Shimano SLX drivetrain paired to FSA Comet cranks, Shimano hydraulic disc brakes, and tubeless-ready WTB Scraper TCS wheels.
Specs
| Frame | 6061-T6 series alloy Hardtail, 27.5-inch Plus / 29-inch geometry, tapered 1.5-inch head tube, 73mm BB shell, Boost thru-axle dropouts |
|---|---|
| Fork | New Recon RL 29"-B Boost; 1-1/8 - 1.5-inch tapered alloy steerer, 120mm travel, Solo Air, thru-axle |
| Headset | FPD Dozer-1048 w/ 1.5-inch ACB bottom for 44/56mm Head Tube |
| Axles |
15x110mm (Front) 12x148mm (Rear) |
| Rims/Wheels | WTB Scraper i35 27.5"Plus, 40mm width, alloy double wall rims w/ TCS i35 rim tape |
| Tires | Kenda Havoc 27.5x2.8", TCS, Aramid Bead 120 tpi |
| Crankset | FSA Comet Modular MegaExo Boost |
| Chainrings | 30T Megatooth Chromoly |
| Bottom Bracket | Mega Exo BB-7100 Boost |
| Chain | KMC X11-1 NP/GY, 1/2-inch x 11/128", 1x11 Specific |
| Rear Derailleur | Shimano SLX, RD-M7000, SGS 10/11-spd Top normal, Shadow Plus design |
| Cassette/Rear Cogs | Shimano CS-M7000, 11-spd 11-46T |
| Shifters | Shimano SLX, SL-M7000, 1x11-spd, Right side only, w/o optical gear display |
| Handlebars | New Pivit X6, 15mm rise, 750 / 785mm wide; 9 Deg. sweep |
| Tape/Grips | WTB Ace Dual Clamps, 135mm |
| Stem | New Pivit X6 alloy Trail, 3D Forged, 0 Deg., 4 bolts, ext.: 60/80mm |
| Brake Levers | Shimano BL-M396 |
| Brakes | Shimano BR-M395 hydraulic, 180/160mm rotors |
| Saddle | WTB Rocket Sport |
| Seat Post | Pivit Internal Dropper post w/ remote, 31.8x100mm |
| Accessories & Extras | Pivit alloy 34.9mm quick release seatpost clamp, Mr. Control alloy direct mount plate cover & CH-CM4 Chain Guide |
* Subject to change without notice.
